● Static torque sensor;
● Compact structure, Easy to install;
● Protection levelIP65;
● Used for measuring static, non-continuous rotational torque values.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 0.1,0.3,1.5,3,6,10,12 N.m | Insulation resistance | ≥5000 MΩ / 100VDC |
| Output sensitivity | ≥0.8 mV/V（0.1~0.3 N.m） ≥1.8 mV/V（1.5 N.m） | Excitation voltage | 5~12V |
| Zero-point balance | ± 3% F.S. | Maximum excitation voltage | 15V |
| Nonlinearity | 0.2％ F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.2％ F.S. | Operating temperature range | -20~80℃ |
| Repeatability | 0.2％ F.S. | Safe load (E L) | 120％ F.S. |
| Creep (30 minutes) | 0.2％ F.S. | Destruction load (E d) | 150％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | |
| Input resistance | 1000±20 Ω | Unit weight | |
| Output resistance | 1000±10 Ω | Protection | IP65 |
Direction of force | Wiring method |
 |  |
