● Static torque sensor
● Compact structure for easy installation
● Protection level：IP65
● Used for measuring static, non-continuous rotational torque values.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
Rated capacity | 0.1~150KN.m | Insulation resistance | ≥5000MΩ/100VDC |
Output sensitivity | 2.0±10%mV/V | Excitation voltage | 5-12V |
Zero output | ±3%mV/V | Maximum excitation voltage | 15V |
| Nonlinearity | 0.1%F.S. | Temperature compensation range | -10~40℃ |
| Hysteresis error | 0.1%F.S. | Operating temperature range | -20-60℃ |
| Repeatability | 0.1%F.S. | Safe overload | 150%F.S. |
| Creep (30 minutes) | 0.1%F.S. | Ultimate overload | 200%F.S. |
| Temperature coefficient of sensitivity drift | 0.05%F.S./10℃ | Protection | IP67 |
| Temperature coefficient of zero drift | 0.05%F.S./10℃ | Cable wire size | φ6×4000mm |
| Input resistance | 775±20Ω | ||
Output resistance | 700±10Ω | ||
Direction of force | Wiring method |
 |  |
