● Integrated product composed of resistive strain gauges and integrated circuits
● High accuracy with stable and reliable performance
● No wear and tear such as slip rings, allowing for high-speed and long-duration operation with output of both positive and negative torque signals
● Key connections on both ends
● Maximum rotational speed not exceeding 4000 RPM
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 0.1,0.2,0.3,0.5,1,2,3,5,10,20 N.m 30,50,100,200,300,500 N.m | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 1.0~1.5 mV/V | Excitation voltage | 12V |
| Zero-point balance | ± 1% F.S. | Maximum excitation voltage | 15V |
| Nonlinearity | 0.2％ F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.2％ F.S. | Operating temperature range | -20~60℃ |
| Repeatability | 0.1％ F.S. | Safe load (E L) | 120％ F.S. |
| Creep (30 minutes) | 0.1％ F.S. | Destruction load (E d) | 150％ F.S. |
| Temperature coefficient of sensitivity drift | 0.02％ F.S./ 10℃ | Cable wire size | 3000m |
| Temperature coefficient of zero drift | 0.02％ F.S./ 10℃ | Material | |
| Input resistance | 350/700±10 Ω | Unit weight | |
| Output resistance | 350/700±10 Ω | Protection | IP66 |
Direction of force | Wiring method |
 |  |
