● Tension measurement sensor, made of stainless steel for strong stability
● Compact structure for easy installation
● IP67 protection level, suitable for various environments
● Widely used for tension detection of various types of lines, including silicon wafer dicing machines, sapphire cutting, crystal cutting, metal wires, optical fibers, carbon fibers, and other types of wire materials.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 10,20,50kg | Insulation resistance | ≥5000MΩ/100VDC |
| Output sensitivity | 1.0±20%mV/V | Excitation voltage | 5~12V |
Zero output | ±0.05mV/V | Maximum excitation voltage | 15 V |
Nonlinearity | 0.1%F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.1%F.S. | Operating temperature range | -20-80℃ |
| Repeatability | 0.05%F.S. | Safe overload | 150%F.S. |
| Creep (30 minutes) | 0.05%F.S. | Ultimate overload | 200%F.S. |
| Temperature coefficient of sensitivity drift | 0.05%F.S/10℃ | Cable wire size | φ5X4000mm |
| Temperature coefficient of zero drift | 0.05%F.S./10℃ | Protection | IP65 |
Direction of force | Wiring method |
 |  |
