● Low profile design for tension measurement.
● High precision with strong resistance to off-center loads.
● Made of Aluminum alloy.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 100g,200g,500g,1kg,2kg | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 1.0±10%mV/V(300g,500g) 2.0±10%mV/V(1~5kg) | Excitation voltage | 5~15V |
| Zero-point balance | ±2% F.S. | Maximum excitation voltage | 20V |
| Nonlinearity | 0.05％F.S. | Temperature compensation range | -10~40℃ |
| Hysteresis error | 0.05％F.S. | Operating temperature range | -25~70℃ |
| Repeatability | 0.05％F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.03％F.S. | Destruction load (E d) | 300％ F.S. |
| Temperature coefficient of sensitivity drift | 0.03％ F.S./ 10℃ | Cable wire size | φ4×400 mm |
| Temperature coefficient of zero drift | 0.03％ F.S./ 10℃ | Material | 0.1kg |
| Input resistance | 380±40 Ω | Single wire weight G | Al alloy |
| Output resistance | 380±40 Ω | Protection | IP65 |
Direction of force | Wiring method |
 |  |
