● Tension Measurement Sensor
● Compact structure for easy installation
● Protection level: IP65
● Extremely strong overload capacity
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 20N-25kN | Temperature coefficient of sensitivity drift | 0.05%F.S/10℃ |
| Output sensitivity | 2.0±0.2%mV/V | Temperature coefficient of zero drift | 0.05%F.S/10℃ |
Zero output | ±2%F.S. | Input resistance | 410±10Ω |
Nonlinearity | 0.25%F.S. | Output resistance | 350±5Ω |
| Hysteresis error | 0.25%F.S. | Operating temperature range | -20-80℃ |
| Repeatability | 0.1%F.S. | 安全载荷 | 120%F.S. |
| Creep (30 minutes) | 0.1%F.S. | Cable wire size | φ5×3000mm |
| Protection | IP65 |
Direction of force |
 |
