| Rated range | 100-1000N | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 1.0±20% mV/V | Excitation voltage | 5~12V |
| Zero output | ±3mV/V | Maximum excitation voltage | 15V |
| Nonlinearity | 0.3％F.S. | Temperature compensation range | -10~40℃ |
| Hysteresis error | 0.3％F.S. | Operating temperature range | -20~60℃ |
| Repeatability | 0.3％F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.3％F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | φ5×3000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | |
| Input resistance | 375±20 Ω | Single wire weight G | |
| Output resistance | 300±20Ω | Protection | IP66 |
Direction of force | Wiring method |
 |  |
