● Column-type weighing sensor, stainless steel material, laser welding sealing.
● Double-headed rocking column design, fast dynamic response.
● Protection level IP68, suitable for weighing in harsh environments such as vehicle scales and railway scales.
● Column-type structure has strong overload resistance and impact resistance, with rated load capacity.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 10,20,30,50t | Insulation resistance | ≥5000MΩ/100VDC |
| Output sensitivity | 2±0.5%mV/V | Excitation voltage | 3~12V |
Zero output | ±2%F.S. | Maximum excitation voltage | 15 V |
Nonlinearity | 0.017%F.S. | Temperature compensation range | -10-60℃ |
| Hysteresis error | 0.017%F.S. | Operating temperature range | -30-70℃ |
| Repeatability | 0.017%F.S. | 安全载荷 | 150%F.S. |
| Creep (30 minutes) | 0.017%F.S. | Destruction load | 200%F.S. |
| Temperature coefficient of sensitivity drift | 0.01%F.S/10℃ | Cable wire size | φ5.4×10m |
| Temperature coefficient of zero drift | 0.02%F.S./10℃ | Material | Stainless Steel(Stainless steel) |
| Input resistance | 780±20Ω | Protection | IP68 |
| Output resistance | 700±10Ω | ||
Direction of force | Wiring method |
 |  |
