● Small size.
● Stainless steel/Alloy steel material.
● Monitoring of threaded force.
● Used in applications such as automotive press-in, automated assembly, testing of 3C products, assembly of new energy products, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 10,15,20,30,50,100t | Insulation resistance | ≥5000MΩ/100VDC |
Accuracy grade | C3 | Excitation voltage | 5~15V |
| Output sensitivity | 2.0±0.005%mV/V | Maximum excitation voltage | 15 V |
Zero output | ±2%F.S. | Temperature compensation range | -10-60℃ |
Nonlinearity | 0.02%F.S. | Operating temperature range | -20~80℃ |
| Hysteresis error | 0.02%F.S. | Safe overload | 150%F.S. |
| Repeatability | 0.02%F.S. | Ultimate overload | 200%F.S. |
| Creep (30 minutes) | 0.02%F.S. | Cable wire size | φ6×13000mm |
| Temperature coefficient of sensitivity drift | 0.0166%F.S./10℃ | Material | Stainless Steel(Stainless steel) |
| Temperature coefficient of zero drift | 0.0166%F.S./10℃ | Protection | IP68 |
| Input resistance | 390±5Ω | Output resistance | 350±5Ω |
Direction of force | Wiring method |
 |  |
