● Stainless steel material, strong stability.
● Suitable for various environments, IP68.
● Stable structure, strong resistance to lateral forces. Mainly used in weighing systems for construction machinery, garbage trucks, and other applications.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 550, 880 kg | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 2.0±0.5% mV/V | Excitation voltage | 5~15 V |
| Zero-point balance | ±5% F.S. | Maximum excitation voltage | 20 V |
| Nonlinearity | 0.05％ F.S. | Temperature compensation range | -10〜40℃ |
| Hysteresis error | 0.05％ F.S. | Operating temperature range | -30〜70℃ |
| Repeatability | 0.05％ F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.05％ F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S. / 10℃ | Cable wire size | φ5.3×2000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S. / 10℃ | Material | 0.6 kg |
| Input resistance | 350±20 Ω | Unit weight (G) | Stainless steel (stainless steel) |
| Output resistance | 350±10 Ω | Protection | IP68 |
Direction of force | Wiring method |
 |  |
