● Low height, minimal deformation. Easy installation.
● Stainless steel/Alloy steel material.
● Can replace the traditional adjustment feet of platform scales and floor scales.
● Suitable for force measurement in various small spaces, widely used in industrial, research and development fields for measurement and control purposes.
● Patented product, infringement will be pursued。
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 0.5,1,1.5,2,2.5 t | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 2.0±0.1% mV/V | Excitation voltage | 5~15 V |
| Zero-point balance | ±0.03 mV/V | Maximum excitation voltage | 20 V |
| Nonlinearity | 0.05％ F.S. | Temperature compensation range | -10〜60℃ |
| Hysteresis error | 0.05％ F.S. | Operating temperature range | -20〜80℃ |
| Repeatability | 0.02％ F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.05％ F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S. / 10℃ | Cable wire size | φ4×4000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S. / 10℃ | Material | |
| Input resistance | 780±20 Ω | Unit weight (G) | |
| Output resistance | 700±10 Ω | Protection | IP67 |
Direction of force | Wiring method |
 |  |
