● Al alloyMaterial
● High precision, strong resistance to bias load
● Easy to install, IP67
● Suitable for electronic scales, counting scales, electronic balances, and industrial weighing systems.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 150,300,500kg | Insulation resistance | ≥5000MΩ/100VDC |
| Accuracy grade | C3 | Excitation voltage | 5-15V |
Output sensitivity | 2.0±10%mV/V | Maximum excitation voltage | 15 V |
Zero output | ±2%F.S. | Temperature compensation range | -10-40℃ |
Nonlinearity | 0.0166%F.S. | Operating temperature range | -10-50℃ |
| Hysteresis error | 0.0166%F.S. | Safe load (E L) | 150%F.S. |
| Repeatability | 0.02%F.S. | Destruction load (E d) | 200％ F.S. |
| Creep (30 minutes) | 0.017%F.S. | Cable wire size | φ6×3000mm |
| Temperature coefficient of sensitivity drift | 0.017%F.S./10℃ | Material | aluminum alloy |
| Temperature coefficient of zero drift | 0.02%F.S./10℃ | Unit weight (G) | 0.6kg |
| Input resistance | 420±20Ω | Protection | IP67 |
| Output resistance | 350±10Ω | Maximum pan size | 600mm×500mm |
Direction of force | Wiring method |
 |  |
