● Stainless steel materials have strong stability.
● High comprehensive sensitivity and compact structure.
● Four-corner deviation has been compensated.
● Maintaining good stability for a long time.
● Mainly used for stainless steel waterproof scales and process weighing in the chemical and pharmaceutical industries.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 50,80,100,150,200,250, 300,350,400,500 kg | Insulation resistance | ≥5000MΩ/ 100VDC |
| Sensitivity | C3 | Excitation voltage | 5~15 V |
| Zero-point balance | 2.0±10% mV/V | Maximum excitation voltage | 20 V |
| Nonlinearity | ±2％F.S. | Temperature compensation range | -10〜40℃ |
| Hysteresis error | 0.0166％F.S. | Operating temperature range | -35〜65℃ |
| Repeatability | 0.0166％F.S. | Safe load (E L) | 150％F.S. |
| Creep (30 minutes) | 0.017％F.S. | Destruction load (E d) | 300％F.S. |
| Temperature coefficient of sensitivity drift | 0.017％F.S. / 10℃ | Cable wire size | φ5.3×2000 mm |
| Temperature coefficient of zero drift | 0.02％F.S. / 10℃ | Material | 0.6 kg |
| Input resistance | 420±20Ω | Unit weight (G) | Al alloy |
| Output resistance | 350±10Ω | Protection | IP67 |
Direction of force | Wiring method |
 |  |
