● Mainly used in fixed value control, weight transmission, checkweighing applications, packaging applications, filling applications, multiple dosage applications, etc.
Standardly equipped with 2 serial ports (RS232+RS232/485).
Support 100M Ethernet communication, MODBUS-RTU, MODBUS-TCP communication.
● OLED dot-matrix display, green, Chinese display menu or English display menu
● Remote configuration of parameters, calibration and locking of the keyboard via serial port, PLC option interface and Ethernet port.
● Option interface
8-input/12-output option boards, PROFIBUS-DP option boards
4-20mA analog output option boards
CC-LINK option boards, PROFINET option boards
● The power supply of the controller adopts AC 86~264VAC, and the loss of the whole machine is less than 6W - IP65 protection of panel type, IP69K protection of dust-proof type; explosion-proof type: gas explosion-proof and dust-proof.
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics field, mold assembly and other industrial testing, measurement and control systems.
Specifications | Technique |
Display | 128X64 OLED dot-matrix display with Chinese and English display menus |
Display division | 150000d |
Output linear | <0.002% |
Comprehensive accuracy | Better than 0.01% |
A/D Conversion speed | ≤200times/second |
Accept sensor | 0.1~+20mV |
Input load | 1-8 350Ω sensorcells |
Communication | RS485--Modbus TCP |
Upgrade Communication | 100Hz PROFIBUS-DP PLC data update speed 50Hz MODBUS-RTU, MODBUS-TCP communication data update rate |
Temp.effect on output | ≤10ppm/℃ |
Temp.effect on zero | ≤10μV/℃ |
Excitation voltage | 5VDC |
Power supply | 86-264VAC |
Power waste | ≤6W |
Operation temp range | -20X70℃ |
Weight approx | 0.5kg |
Material | Stainless Steel (explosion proof optional) |
IP Class | Panel mounted IP65 protection, dustproof IP69K protection |
