● Mainly used in platform scales, platform scales, vehicle scales, Over/Under/OK sorting scales, counting scales, livestock scales.
● Output support RS232/485, WIFI, Ethernet TCP/IP, Bluetooth.
● 6-digit 33.4mm character height, red or green LED display.
● Basic weighing functions: zero, tare, clear and print, auto tare, auto clear and auto print.
● Controller power supply adopts AC 86~264VAC, current: 0.1A. NiMH rechargeable battery pack, GP7.2VDC3800mAh.(Option)
● Stainless steel waterproof casing, protection class: IP66, plastic casing is also available.
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics field, mold assembly and other industrial testing, measurement and control systems.
Specifications | Technique |
Display | 6 digits red or green LED display 6digits red or green display |
Display division | 200000d |
Output linear | X0.002% |
Comprehensive accuracy | Better than 0.01% |
A/D Conversion speed | ≤50 times/second times/second |
Accept sensor | 0.1-+20mV |
Input load | 1×8 350Ω sensorcells |
Communication | RS485/RS232--Modbus |
Temp.effect on output | ≤10ppm/℃ |
Temp.effect on zero | ≤10μV/℃ |
Excitation voltage | 5VDC |
Power supply | 86-264VAC |
Power waste | ≤10W |
Operation temp range | -20X70℃ |
Weight approx | 0.5kg |
Material | Stainless Steel (plastic optional) |
IP Class | IP66 |
