● Fully isolated design, power supply, sensor, serial port and option board are isolated from each other.
● Weight-free calibration, adaptable to complex weighing conditions.
● TEDS interface, calibration free with TESD sensor.
● Built-in application programs, upper and lower limits, checkweighing, preset points, peak capture and comparison.
● Measurement, analysis and control functions can be added according to customers' requirements.
● Optional ±10V/4~20mA, Ethernet, ProfiBUS-DP, ProfiNETIRT, EtherNet/IP and other industrial communication interfaces.
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics field, mold assembly and other industrial testing, measurement and control systems.
Comprehensive Accuracy | % | 0.01 |
determining index (i.e. measuring interval) | e | 10000 |
Measurement sensitivity | μV/e | ≥0.5 |
minimum sensitivity | μV/e | 0.02 |
Measured signal range | mV/V | ±2.0 |
Maximum Signal Input Range | mV/V | ±5.0 |
Bridge Road Power Supply | VDC | 5±1% |
Measurement resolution for rated input signals | 1:1000000 | |
range (of scales or measuring equipment) | stage (of a process) | 2 |
linear calibration | stage (of a process) | 5 |
measuring rate | times/second | 200;100;50;25;10 |
Digital Filter Cutoff Frequency | HZ | 10；...0.3 |
communication interface | RS232 or RS485 | |
Operating supply voltage | VDC | 18~32 |
Operating Temperature Range | ℃ | -30...+65 |
