●Used in situations where force measurement signals need to be converted into digital communication signals, standard analog output signals, and simple control
●Analog output signals can be selected from 0-20mA or 4-20mA 0-10V, 1-5V, digital communication interface can choose RS485 or RS232
●Double row 6-digit LED digital tubes display real-time measurement values, peak values, output current values, and 1 I/O status information respectively
●The controller has the function of judging the upper limit, middle limit, and lower limit limits
●I/O has 4 inputs and 6 outputs, with customizable input and output port functions
●It can drive the controller output through the upper computer and partially replace the PLC
●The controller power supply adopts DC24V power supply, with a voltage range of 5V, which is safer and more stable
●Open panel installation, with a panel area of only 110mm (width) x 62mm (height)
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Display window | Double row 6-digit LED display | Zero temperature drift | ≤10μV/°C |
| Readability | 1/90000 | Excitation | 5VDC |
| Output linearity | <0.002% | Power supply | 24土5VDC |
| Comprehensive accuracy | Better than 0.01% | Overall power consumption | ≤10W |
| A/D conversion speed | ≤400times/second | Operating temperature range | -20~70C |
| Acceptance sensitivity | -3.6-+3.6 mVN | Single piece weight | 0.5kg |
| Input load | 1-8 3502 sensor cells | Material | Aluminum alloy |
| Output specifications | 士10V10~10V 14~20mA | Protection grade | IP65 |
| Full scale temperature drift | ≤10ppm /C |
