●Used in situations where force measurement signals need to be converted into digital communication signals, standard analog output signals, and simple control
●Equipped with a standard serial port RS485 or RS232, supporting Modbus RTU protocol
●6-digit LED digital tube with a height of 7.1mm and 4 status indicator lights
●The controller has the function of judging the upper limit, middle limit, and lower limit limits
●Optional up to 8 outputs and 8 inputs
●5-level dynamic digital filtering, with a comparison speed of 200 times per second
●It can drive the controller output through the upper computer and partially replace the PLC
●Standard industrial rail installation (DIN)
●Applicable to fixed value control systems, weighing scales, packaging scales, process force measurement and control
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Display window | Double row 6-digit LED display | Zero temperature drift | ≤10μV/℃ |
| Readability | 1/9000 | Excitation | 5VDC |
| Output linearity | <0.002％ | Power supply | 24±5VDC |
| Comprehensive accuracy | Better than 0.01% | Overall Power Consumption | ≤10W |
| A/d conversion speed | ≤ 400 times/second | Operating temperature range | -20～70℃ |
| Acceptance sensitivity | -3.6〜+ 3.6 mV/ V | Single piece weight | 0.5 KG |
| Input load | 1-8 350 Ω sensors | Material | Aluminum alloy |
| Output specifications | ±10V / 0～10V / 4～20mA | Protection grade | IP65 |
| Full scale temperature drift | ≤10ppm/℃ |
