●Multipoint linear calibration
● Multiple ranges, divisions, and sampling frequencies
● Standard ModBUS-RTU communication
● Protection level IP66
●One in one out digital transmitter
●Wide power supply: 7~25VDC
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Comprehensive accuracy level | 0.01 | Interface | RS485/2W |
| Linear Calibration | 5 | Communication protocol | Modbus RTU protocol |
| Calibration graduation number | 10000 | Supply Voltage | 7~ 25 |
| Measurement sensitivity | ≥0.5 | Overall power consumption | ≤0.2 |
| Minimum sensitivity | 0.02 | Operating temperature range | -30~ 65 |
| Measurement signal range | 2 | Single piece weight | 0.17kg |
| Maximum signal input range | 土5.0 | Material | Aluminum alloy |
| Bridge power supply | 3.3土1% | Protection grade | IP66 |
| Measurement resolution of rated input signal | 1:1000000 |
