● 5 times overload capacity, low height, minimal deformation, easy installation.
● Tension and compression measurement in both directions.
● Mainly used for push-pull force measurement, contact force testing, automotive assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, and mold assembly.
● Suitable for button force testing, contact force testing, automotive assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, and mold assembly.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 2,5,10,20,50 kg | Insulation resistance | ≥2000 MΩ / 100VDC |
| Sensitivity | 2.0±10% mV/V | Excitation voltage | 5V |
| Zero-point balance | ± 3% F.S. | Maximum excitation voltage | 15V |
| Nonlinearity | 0.05% F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.1% F.S. | Operating temperature range | -20~80℃ |
| Repeatability | 0.1% F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.1% F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | φ5×3000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | Al alloy |
| Input resistance | 385±20 Ω | Unit weight | 0.4 kg |
| Output resistance | 350±10 Ω | Protection | IP65 |
Direction of force | Wiring method |
 |  |
