● precision with strong resistance to bias load.
● Easy to install, with an IP66 protection level.
● Custom specifications can be accommodated.
● Used for precision control of robotic arms, surface grinding and polishing, precision engraving in machining centers, and precise measurements in medical equipment.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 50,100,200,400 N.m (Customizable其他Measurement range） | Insulation resistance | ≥5000 MΩ / 100VDC |
| Rated output | 1.0~1.5 mV/V | Excitation voltage | 5~12V |
| Zero-point balance | ± 3% F.S. | Maximum excitation voltage | |
| Nonlinearity | 0.3％ F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.5％ F.S. | Operating temperature range | -20~80℃ |
| Repeatability | 0.3％ F.S. | Safe load (E L) | 120％ F.S. |
| Creep (30 minutes) | 0.3％ F.S. | Destruction load (E d) | 150％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | φ3×4000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | |
| Input resistance | Direction of force | ||
| Output resistance | Protection | IP65 |
Direction of force | Wiring method |
 |  |
