● Good stability with strong resistance to bending moments and long frequency life. Static torque sensor.
● Compact structure for easy installation.
● Protection level: IP65.
● Used for measuring static, non-continuous rotational torque values. Specifically designed for professional screwdrivers, screw tightening, etc.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 5,10,20,50,100 N.m | Insulation resistance | ≥5000 MΩ / 100VDC |
| Rated output | -10V ~ +10V | Excitation voltage | 24V |
| Zero-point balance | ± 0.05 mV/V | Maximum excitation voltage | |
| Nonlinearity | 0.3％ F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.3％ F.S. | Operating temperature range | -20~80℃ |
| Repeatability | 0.3％ F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.3％ F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | φ5×4000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | Alloy steel |
| Input resistance | 780±20 Ω | Direction of force | 逆时针为正 |
| Output resistance | 700±10 Ω | Protection | IP65 |
Direction of force | Wiring method |
 |  |
