● stability.
● Suitable for various environments, protection level: IP67.
● Maximum capacity up to 5000T.
● Mainly used in force measurement equipment.
● Can be used as a measurement standard source for calibration.
● High accuracy, good reliability, fatigue resistance, high frequency of use, good creep performance, low temperature drift, high dynamic response frequency.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 50,100,200,500,1000,2000,3000, 5000,10000,20000,50000 kN | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | -2.0 mV/V | Excitation voltage | 5V |
| Zero-point balance | ± 1% F.S. | Maximum excitation voltage | 15V |
| Nonlinearity | 0.02％F.S,0.05%F.S. 0.1%F.S.,0.3% F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.02％F.S,0.05%F.S. 0.1%F.S.,0.3% F.S. | Operating temperature range | -30~70℃ |
| Repeatability | 0.02％F.S,0.05%F.S. 0.1%F.S.,0.3% F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.02％F.S,0.05%F.S. 0.1%F.S.,0.3% F.S. | Destruction load (E d) | 300％ F.S. |
| Temperature coefficient of sensitivity drift | 0.05％ F.S./ 10℃ | Cable wire size | φ5.4×6000 mm |
| Temperature coefficient of zero drift | 0.05％ F.S./ 10℃ | Material | Stainless steel / Alloy steel |
| Input resistance | 760±20 Ω | Single wire weight G | |
| Output resistance | 700±10 Ω | Protection | IP67 |
Direction of force | Wiring method |
 |  |
