● Low height, small deformation, small outer dimensions.
● Made of stainless steel material, high accuracy.
● Protection level: IP68, suitable for outdoor or harsh environments.
● High accuracy, long-term stability, good reliability, fatigue resistance, high frequency of use, good creep performance, low temperature drift, high dynamic response frequency.
● Used in automotive press-fitting, automated assembly, 3C product testing, assembly of new energy products, medical testing, robotics. Also commonly used for weighing in storage, silos, and reactors, with low height and stability.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 25,50,100,250,500 kN | Insulation resistance | ≥5000 MΩ / 100VDC |
| Sensitivity | 2.0±1％ mV/V | Excitation voltage | 5~15V |
| Zero-point balance | ± 0.05% mV/V | Maximum excitation voltage | 20V |
| Nonlinearity | 0.5％ F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.3％ F.S. | Operating temperature range | -10~80℃ |
| Repeatability | 0.2％ F.S. | Safe load (E L) | 150％ F.S. |
| Creep (30 minutes) | 0.2％ F.S. | Destruction load (E d) | 200％ F.S. |
| Temperature coefficient of sensitivity drift | 0.03％ F.S./ 10℃ | Cable wire size | φ5×5000 mm （25~100 kN） φ5×10000 mm （250~500 kN） |
| Temperature coefficient of zero drift | 0.03％ F.S./ 10℃ | Material | Stainless steel |
| Input resistance | 385/780±20 Ω | Single wire weight G | |
| Output resistance | 350/700±10 Ω | Protection | IP68 |
Direction of force | Wiring method |
 |  |
