● 5 times overload capacity, low height, minimal deformation, easy installation.
● Tension and compression measurement in both directions.
● Mainly used for push-pull force measurement, hopper scales, and various industrial weighing systems.
● Suitable for button force testing, contact force testing, automotive assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, and mold assembly.
● This is a patented product, and infringement will be pursued.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 20t | Insulation resistance | ≥5000MΩ/100VDC |
Output sensitivity | ±0.2mV/V | Excitation voltage | 5-12V |
Zero output | ±1%F.S. | Maximum excitation voltage | 15V |
| Nonlinearity | 0.1%F.S. | Temperature compensation range | -10~60℃ |
| Hysteresis error | 0.1%F.S. | Operating temperature range | -40-80℃ |
| Repeatability | 0.03%F.S. | Safe overload | 150%F.S. |
| Creep (30 minutes) | 0.05%F.S. | Ultimate overload | 300%F.S. |
| Temperature coefficient of sensitivity drift | 0.05%F.S/10℃ | Protection | IP66 |
| Temperature coefficient of zero drift | 0.03%F.S/10℃ | Cable size | φ6x1m (Waterproof cable) |
Input resistance | 780±20Ω | Service life | 1 million times |
Output resistance | 700±10Ω | ||
Direction of force | Wiring method |
 |  |
