● Specialized waterproof connector
● Highly stable multi-turn potentiometer for compensation adjustment.
● The cover plate has a waterproof rubber gasket, which is waterproof and dustproof, and is suitable for industrial sites with harsh environmental conditions.
● Prevents damage to the sensor from induced lightning and surge signals.
● One-in-one-out junction box
● Multiple signal integration
● Application areas: automotive press fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics field, mold assembly and other industrial test, measurement and control systems.
| Output specification | ±10V/0~10V/4~20mA | Excitation voltage | 5VDC |
| Output linearity | Better than 0.1% | Power supply (of an appliance etc) | 9~26 VDC |
| Comprehensive accuracy | Better than 0.1% | Power Consumption | ≤0.2 W |
| Acceptance sensitivity | 0.3mV/V~8mV/V | Operating temperature range | -20~60℃ |
| Input load | 1-2 sensors | Unit weight | 0.17 kg |
| Output ripple | ≤2 mVp-p | Makings | Aluminum |
| Output load | ≤500 Ω | Protection level | IP 66 |
